INSTRUCTIONS AND INFORMATION

1. This question paper consists of FOUR questions
2. Answer ALL the questions
3. ALL drawings are in third-angle orthographic projection, unless otherwise stated.
4. ALL drawings must be prepared using pencil and instruments, unless otherwise stated.
5. ALL answers must be drawn accurately and neatly
6. ALL the questions must be answered on the QUESTION PAPER, as instructed.
7. ALL the pages, irrespective of whether the question was attempted or not, must be re-stapled in numerical sequence in the TOP LEFT-HAND CORNER ONLY.
8. Time management is essential in order to complete all the questions
9. Print your examination number in the block provided on every page.
10. Any details or dimensions not given must be assumed in good proportion.
