ENGINEERING GRAPHICS AND DESIGN PAPER 1 GRADE 12 MEMORANDUM - NSC PAST PAPERS AND MEMOS NOVEMBER 2016
Share via Whatsapp Join our WhatsApp Group Join our Telegram GroupENGINEERING GRAPHICS AND DESIGN
PAPER 1
GRADE 12
NSC PAST PAPERS AND MEMOS
NOVEMBER 2016
MEMORANDUM
| QUESTIONS | ANSWERS | ||
| 1 | How many signatures are required? | 2 | 1 |
| 2 | Who prepared the drawing? | WILLIAM/"ON THE DOT ARCHITECTS" | 1 |
| 3 | What scale is indicated for the drawing? | 1:800 | 1 |
| 4 | Who checked the drawing? | VERNON | 1 |
| 5 | Who is responsible for the printing of the site plan? | NAT PRINTERS | 1 |
| 6 | How many times has the drawing been revised? | 0/NONE/NOT APPLICABLE | 1 |
| 7 | When was the site survey? | 2015-05-06 | 1 |
| 8 | How many rodding eyes are shown on the site plan? | 2/3 | 1 |
| 9 | What does the abbreviation IC stand for? | INSPECTION CHAMBER | 1 |
| 10 | In what color should glass be indicated on a detailed drawing? | BLACK | 1 |
| 11 | Name the feature at 1. | CONTOUR LINE | 1 |
| 12 | In what unit are the dimensions of the site plan? | MILLIMETRE/MM/METRIC | 1 |
| 13 | On what must the new paving be laid? | COMPACTED HARD CORE | 1 |
| 14 | What type of fence is proposed for the complex? | ELECTRIC SECURITY FENCE | 2 |
| 15 | What is indicated by the arrow at 2? | GATE OPENING DIRECTION | 1 |
| 16 | Why would a residential stand not be allowed on the land immediately south-west of STAND 3? | SERVITUDE | 2 |
| 17 | Referring to the building regulations, why would this proposed site plan not be approved? | STORETOOM OVER BUILDING LINE | 2 |
| 18 | In the space below(ANSWER 18). determine the length of the electric security fence in meters. | 369,14m (calculations 1, answer 1, meters 1) | 3 |
| 19 | In the space below(ANSWER 19), determine the combined total are of ALL the proposed buildings in square meters. | 2184m2 (calculations 2, answer 1, meters2 1) | 4 |
| 20 | In the space in the title panel above (ANSWER 20), draw, in neat freehand, the front view and the top view of the SANS 10143 graphic symbol for a BIDET. | ANSWER BELOW | 3 |
| TOTALS | 30 | ||
ANSWER 18 | ANSWER 19 SHOW ALL CALCULATIONS. |
L = 2(L + B) =138,138 - GATE | B A = 9[(12,4 × 20) - (4 × 4) + (12 × 8)] =9 (248 - 16) + 96 =2088 + 96 2184m2 |
